BlueSolar PWM-Pro Charge Controller 12/24V-20A
The BlueSolar PWM-Pro Charge Controller from Victron Energy is a versatile solution for larger solar energy systems. With its default settings, it's ready for immediate use, but for those who need a tailored approach, it's fully programmable. This controller boasts a lighting control function, three-stage battery charging, and an integrated battery monitor function. To get a detailed view of the state of charge, a remote panel is essential. The load output is designed with protection against overload and short circuits. Additionally, the unit is protected against any reverse polarity connection from the solar panels and/or battery. The controller also offers day/night timing options, enhancing its flexibility.
Features
- Lighting control function, fully programmable.
- Three-stage battery charging (bulk, absorption, float), fully programmable.
- Integrated battery monitor function (Remote Panel needed to display state of charge).
- Load output with low voltage disconnect and manual control (default setting).
- Optional external temperature sensor.
- Day/night timing options.
Specifications
- Battery Voltage: 12/24V Auto Select
- Rated Charge Current: 20A
- Recommended Solar Panel: 110W-880W (12V), 220W-1760W (24V)
- Maximum Solar Voltage: 28V (12V system), 55V (24V system)
- Enclosure: IP20
Shipping
- Dimensions (HxWxD): 70 x 133 x 33,5 mm
- Weight: 0,2kg
Warranty
This product comes with a 5-year warranty.
