BlueSolar PWM-Pro Charge Controller 12/24V-5A
The BlueSolar PWM-Pro Charge Controller from Victron Energy is a versatile solution for solar energy systems. It comes ready for use with default settings but is also fully programmable to cater to specific needs. The controller offers a lighting control function, three-stage battery charging, and an integrated battery monitor function. For a comprehensive view of the state of charge, a remote panel is required. The load output is protected against overload and short circuits, and the unit itself is safeguarded against reverse polarity connection of the solar panels and/or battery. Additionally, the controller provides day/night timing options for added flexibility.
Features
- Lighting control function, fully programmable.
- Three-stage battery charging (bulk, absorption, float), fully programmable.
- Integrated battery monitor function (Remote Panel needed to display state of charge).
- Load output with low voltage disconnect and manual control (default setting).
- Optional external temperature sensor.
- Day/night timing options.
Specifications
- Battery Voltage: 12/24V Auto Select
- Rated Charge Current: 5A
- Recommended Solar Panel: 55W-440W (12V), 110W-880W (24V)
- Maximum Solar Voltage: 28V (12V system), 55V (24V system)
- Enclosure: IP22
Shipping
- Dimensions (HxWxD): 113 x 100 x 40 mm
- Weight: 0,15kg
Warranty
This product comes with a 5-year warranty.
