Victron MultiPlus 24/5000/120-100

The MultiPlus 24/5000/120-100 is a versatile inverter/charger from Victron Energy. It combines a powerful true sine wave inverter, an advanced battery charger with adaptive charge technology, and a high-speed AC transfer switch in a single compact unit. The MultiPlus ensures uninterrupted power supply and efficient power management, making it ideal for various applications.

Features

• Two AC Outputs: The main output provides a no-break functionality, ensuring a swift takeover during grid failures or when shore/generator power disconnects. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption. The second output is live only when AC is available on the MultiPlus input, perfect for loads that shouldn't deplete the battery.
• Parallel Operation: Up to 6 MultiPlus units can operate in parallel for higher power output. For instance, six 24/5000/120 units will provide 25 kW / 30 kVA output power with 720 Amps charging capacity.
• Three Phase Capability: In addition to parallel connection, three units of the same model can be configured for three-phase output. Furthermore, up to 6 sets of three units can be parallel connected for a 75 kW / 90 kVA inverter and more than 2000 Amps charging capacity.
• PowerControl: Efficiently manages limited generator, shore, or grid power.
• PowerAssist: Enhances the capacity of shore or generator power by adding inverter power when necessary.

Specifications

• Inverter:
  • Input voltage range: 19 – 33 V
  • Output voltage: 230 VAC ± 2%
  • Frequency: 50 Hz ± 0.1%
  • Continuous output power at 25°C: 5000 VA
  • Continuous output power at 40°C: 4000 W
  • Peak power: 10,000 W
  • Maximum efficiency: 94 / 95%
  • Zero load power: 30 / 35 W
  • Zero load power in Search mode: 10 / 15 W
• Charger:
  • Input voltage range: 187-265 VAC
  • Charge voltage 'absorption': 28.8 V
  • Charge voltage 'float': 27.6 V
  • Storage mode: 26.4 V
  • Charge current house battery: 120 A
• General:
  • Operating temperature range: -40 to +65°C (fan-assisted cooling)
  • Humidity: max 95% (non-condensing)
  • Weight: 30 kg
  • Dimensions (HxWxD): 444 x 328 x 240 mm

Shipping

• Weight: 30 kg

Warranty

• This product comes with a 5-year warranty.
