Victron MPPT SmartSolar 250/60-MC4
The SmartSolar MPPT 250/60-MC4 is a highly efficient solar charge controller from Victron Energy. It employs the latest and fastest technology to maximize energy harvest from the PV array by intelligently adjusting itself to achieve the most efficient energy charge. The SmartSolar MPPT ensures the batteries are maintained in the best possible condition and can extend their life. With advanced features such as Maximum Power Point Tracking (MPPT), the SmartSolar controller ensures you get the most out of your solar panels.
Features
- MPPT Technology - Ultra-fast maximum power point tracking ensures up to 30% more energy harvest compared to PWM charge controllers.
- Advanced MPPT Detection - In case of partial shading conditions, the innovative SmartSolar algorithm will always maximize energy harvest by locking to the optimum MPP.
- High Efficiency - Outstanding conversion efficiency with no cooling fan required. Maximum efficiency exceeds 98%.
- Flexible Charge Algorithm - Fully programmable charge algorithm with eight pre-programmed algorithms selectable via a rotary switch.
- Extensive Electronic Protection - Features over-temperature protection, PV short circuit and reverse polarity protection, and PV reverse current protection.
- Bluetooth Smart Built-in - Enables wireless setup, monitoring, and updates.
- Remote Monitoring & Control - When connected to the internet, access the full power of your MPPT charger via the Victron Remote Management Portal (VRM).
- VE.Direct or VE.Can - For a wired data connection to other devices.
Specifications
- Battery Voltage - 12/24/36/48V Auto Select
- Rated Charge Current - 60A
- Maximum PV Open Circuit Voltage - 250V
- Maximum PV Short Circuit Current - 60A
- Maximum PV Input Power - 860W (12V), 1720W (24V), 2580W (36V), 3440W (48V)
- Operating Temperature - -30°C to +60°C (full rated output up to 40°C)
- Protection - IP43
Shipping
- Dimensions (HxWxD): 130 x 186 x 70 mm
- Weight: 2.5 kg
Warranty
This product comes with a 5-year warranty.
